• Digital signage
• Additional devices needing PoE or
PoE+ signal
System overview
The CommScope powered fiber cable system
is a hybrid fiber/ copper system that installs
like a “long extension cord” and is comprised
of the following system elements:
• Hybrid cable
• PoE extender
• Safety & overload protection
• Power supply
• Power transmission management
• Cable/fiber management
Hybrid fiber/copper cabling
• 12 AWG (2mm) and 16 AWG (1.2mm)
conductor size options
• From one to twelve optical fibers, G657
A2 single mode or OM3 multimode
• Outdoor rated polyethylene (PE) and
indoor/outdoor low smoke zero halogen
(LSZH/Riser) rated options
• No special cable access tools needed
• Uses commonly available flat cable
installation hardware.
PoE extender
• DC/DC conversion electronics
• Eliminates electrical engineering
calculations by converting the received
voltage to the correct DC voltage level for
PoE output (48VDC)
• Provides three separate levels of electrical
protection per ITU.T K21 and Telcordia
GR-1089 to protect the device (small cell,
Wi-Fi AP, camera, etc.) and personnel
• SELV and NEC Class II compliant
• Outdoor rated
• Houses electronics, power
termination, fiber management,
and cable termination
• Unobtrusive installation
• Fits in one hand
• Provides a single PoE (IEEE 802.3af-
2003) and PoE+ (IEEE 802.3at-2009)
compliant output. •
